Features: The program supports many control units,you can also run output tests on many controllers. The speed of the communication over the USB-BUS is enough to handle the awesome speed of the High-Speed CAN-BUS systems, which is currently 500kbps Reset, and program the following immobiliser related items: ECM, BCM, IPC. Since Opel uses many pin in the OBD connector, the diagnostic interface works as a multiplexer, and selects the appropriate pin for communication. The diagnostic inteface is USB port based, so there will be NO COMPATIBILITY ISSUES, with serial to USB converters PIN3, PIN7, PIN8, PIN12 = Serial Link (ISO9141, KW81, KW82, KWP2000) The program shows you measuring block information on many control module, you can choose anything from the list on your own The program is capable of showing 8 measuring block parameter simultaneously. The sample rate is depends mostly on the communication protocol. PIN6-PIN14,PIN3-PIN11,PIN1 HSCAN - Dual-wire, High Speed CAN-BUS, 500 kbps MSCAN - Dual-wire, Medium Speed CAN-BUS, 95 kbps SWCAN - Single-wire, Low Speed CAN-BUS, 33.3 kbps You will get a feedback on the state of the activated output. This will helps you to find the failed.components more easily.With DIGIOBD OP-COM, you can learn keys to immobiliser, and remote keys to the central door locking You will need the vehicle security code, which can be found on the CAR-PASS You can also reset, and program the Service interval reminder on Astra-G, Zafira, Corsa-C, Meriva You can code SAB6, and SAB8 airbags with the software Package Included: 1 x DIGIOBD OP COM Interface 1 x USB Cable 1 x Software and Drivers CD
